Profipress T-​piece – Model 2418 (mm)

17 Jan

d1 d2 d3 Z1 Z2 Z3 L1 L2 L3
12 12 12 18 9 18 36 27 36
12 15 12 20 10 20 38 32 38
14 12 14 17 12 17 36 30 36
14 14 14 18 12 18 37 31 37
15 12 12 17 12 21 39 30 39
15 12 15 16 12 16 39 30 39
15 15 12 18 11 23 41 33 41
15 15 15 19 11 19 41 33 41
15 18 15 20 13 20 42 35 42
15 22 15 23 15 23 45 38 45
16 12 14 21 12 18 40 30 36
16 14 16 18 13 18 37 32 37
16 16 16 19 13 19 38 32 38
18 12 15 17 13 21 39 31 43
18 12 18 17 13 17 39 31 39
18 14 18 18 15 18 40 34 40
18 15 15 18 13 23 41 35 45
18 15 18 10 13 10 41 35 41
18 16 18 19 15 19 41 34 41
18 18 15 20 13 25 42 35 47
18 18 18 20 13 20 42 35 42
18 22 18 23 13 23 45 36 45
22 12 22 16 15 16 39 33 39
22 14 22 17 17 17 40 36 40
22 15 15 17 15 25 41 37 47
22 15 18 17 15 22 41 37 44
22 15 22 9 15 9 41 37 41
22 16 22 18 17 18 41 36 41
22 18 15 19 15 28 42 37 50
22 18 18 19 15 25 42 37 47
22 18 22 19 15 19 42 37 42
22 22 15 21 15 29 45 38 51
22 22 18 21 15 29 45 38 51
22 22 22 22 15 22 45 38 45
22 28 22 25 15 25 48 39 48
28 15 22 17 19 23 41 41 46
28 15 28 17 19 17 41 41 41
28 18 22 18 19 24 42 41 47
28 18 28 18 19 18 42 41 42
28 22 22 21 19 27 45 42 50
28 22 28 13 19 13 45 42 45
28 28 22 20 19 30 48 43 53
28 28 28 23 19 23 48 43 48
35 15 35 17 22 17 44 44 44
35 18 35 18 22 18 44 44 44
35 22 28 19 22 29 46 45 53
35 22 35 19 22 19 46 45 46
35 28 28 22 22 32 49 46 56
35 28 35 22 22 22 49 46 49
35 35 22 26 22 40 52 48 63
35 35 28 26 22 35 52 48 59
35 35 35 26 22 26 52 48 52
42 22 42 17 29 17 53 52 53
42 28 42 19 29 19 55 53 55
42 35 42 22 29 22 58 55 58
42 42 42 29 29 29 65 65 65
54 22 54 19 35 19 60 58 60
54 28 54 22 35 22 63 59 63
54 35 54 26 35 26 67 61 67
54 42 54 29 35 29 69 71 69
54 54 54 35 35 35 75 75 75
